Brand: NOYITO
Color: Black
Features:
- Product Applications: PLC automation equipment control, industrial system control, Internet of Things control, electronic enthusiasts to develop experiments, all kinds of circuit modification.
- With anti-reverse power function, power supply will not damage when the module reverse.
- High-quality 2A AC solid state relay module. Module anti-interference ability, stable performance, trigger current only 2mA.
- Each channel with relay on / off LED indicator.
- Module load: AC240V 2A Max（Can only control the AC load, can not control the DC load.）.
Details: Electrical parameters: Supply voltage: DC 12V; Quiescent current: 0mA; Maximum operating current: 26.8mA; Trigger mode: high-level trigger; Load voltage: AC 240V; Load current: 2A; Module life: 10 million times; Switch the maximum frequency: ≤ 5KHz; Product weight: 13g; Size: 55x33x25mm (LxWxH); Positioning hole size: 27.4x49.4mm; Trigger voltage range: 12V high-level trigger: DC 6-12V relay on; DC 0-5.5V relay off; Pacakage Included: 1x2-Channel Solid State Relay Module
Package Dimensions: 5.9 x 3.3 x 1.0 inches
